State-of-the-Art Online UV Fluorescence COD Sensor for Sewage Water Treatment Monitoring
Product Details:
| Place of Origin: | China |
| Brand Name: | BINGSHENG |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 pieces |
|---|---|
| Price: | Discussion |
|
Detail Information |
|||
| Warranty: | 1 Years | Customized Support: | OEM, ODM |
|---|---|---|---|
| Product Name: | Digital COD Sensor For Waste Water | Measurement Range: | 0.5 To 370mg/Lequiv KHP |
| Resolution: | 0.01mg/L | Ingress Protection: | IP68 |
| Corresponding Time: | 10 Seconds | Communication Interface: | Supports RS-485 And Modbus Protocols |
| Working Voltage: | DC 12V-24V | Current: | <50mA |
| Self Cleaning: | Built-in Cleaning Brush | ||
Product Description
Product Description
Product name | Low price Industrial Online Chemical Oxygen Demand Monitoring System Temperature Turbidity Digital COD Sensor for Waste Water |
Interface | Supports RS-485 and MODBUS protocols |
COD | Range: 0.75 to 600mg/L equiv.KHP |
COD | Accuracy: <5% equiv.KHP |
TOC | Range: 0.3 to 240mg/L equiv.KHP |
Accuracy: <5% equiv.KHP | |
Range: 0-300 NTU | |
Turbidity | Accuracy＜ 3% or 0.2NTU |
Turbidity | Resolution: 0.1NTU |
Temperature range | +5~50 ℃ |
Shell IP protection level | IP68 |
Shell material | POM |
Maximum withstand pressure | 1 bar |
User calibration | 1 or 2 points |
Power information | 12-24VDC+/-5%, current |
Size | Sensor diameter: 52 mm Sensor length: 178 mm Cable length: 10m (default) |
Features: 1. Used for online monitoring of natural water (rivers, water sources, water stations, buoy); 2. Urban sewage treatment, enterprise sewage discharge monitoring (inlet and outlet of sewage treatment plants, monitoring of rainfall diversion of urban underground pipe lines, multi -parameter integration monitoring, etc.); 3. Enterprise internal monitoring and feedback control (breeding water treatment and emissions, high -density aquaculture and other sewage discharge) 4. Fast detection of laboratory. Application: * Digital sensor, RS-485 output, support Modbus.
* Light path : 254nm, reference light, can effectively eliminate turbidity effects.
* Adopt advanced cold light source UV LED, with long life and small drift.
* The probe is directly immersed in measurement without sampling and pre -processing.
* With automatic cleaning function, it can reduce maintenance.
* The fastest 10 seconds response (T90).
* Low operation costs, rarely maintain daily maintenance, cost -effective.
* No reagent, no pollution.
* Power supply positive and negative anti -connection protection.
* RS485 A/B -end error connection protection.
* Light path : 254nm, reference light, can effectively eliminate turbidity effects.
* Adopt advanced cold light source UV LED, with long life and small drift.
* The probe is directly immersed in measurement without sampling and pre -processing.
* With automatic cleaning function, it can reduce maintenance.
* The fastest 10 seconds response (T90).
* Low operation costs, rarely maintain daily maintenance, cost -effective.
* No reagent, no pollution.
* Power supply positive and negative anti -connection protection.
* RS485 A/B -end error connection protection.
