Temperature PH NPK Moisture EC and Salinity Sensors in Agriculture 7 in 1 Soil Tester Kit
Product Details:
| Place of Origin: | Henan, China |
| Brand Name: | BINGSHENG |
| Model Number: | BSK-TR5.0-100 |
Payment & Shipping Terms:
| Price: | Discussion |
|---|
|
Detail Information |
|||
| Warranty: | 1 Year | Customized Support: | OEM, ODM |
|---|---|---|---|
| Usage: | Industrial, Portable PH Meter | Communication Mode: | Digital |
| Mounting Type: | Horizontal Installation | Output Signal: | RS485(Modbus) |
| Supply: | 5~30V DC | Ingress Protection: | IP68 |
| Response Time: | <1s | Temperature Range: | -40-+80℃ |
| Moisture Range: | 0-100% | EC Range: | 0~20000us/cm |
| PH Range: | 3~10PH | ||
Product Description
Specification
Technical indicators | ||||||
Range | Resolution | Accuracy | ||||
EC | 0~20000us/cm | 1us/cm | ±3%FS(0-10000us/cm) ±5%FS(10000-20000us/cm) | |||
Soil pH | 3~10PH | 0.1 | ±0.3PH | |||
Temperature | -40~80℃ | 0.1℃ | ±0.5℃ | |||
Moisture | 0~100% | 0.1% | ±2%(0-50%) ±3%(50-100%) | |||
NPK | 1-1999mg/kg(mg/L) | 1mg/kg(mg/L) | ±2%FS | |||
Output Signal | RS-485(Modbus Protocol) | |||||
Power supply | 5~30V DC | |||||
Power consumption | 0.5W MAX (24VDC power supply) | |||||
Probe material | Anti-corrosion special electrode | |||||
Operating Temperature | -20-+60℃ | |||||
Ingress Protection | IP68 | |||||
Product Description
The transmitter has stable performance, high sensitivity, fast response and stable output, and is suitable for various soil types. It is an important tool to observe and study the occurrence, evolution, improvement and water-salt dynamics of saline soil. By measuring the dielectric constant of soil, it can directly and stably reflect the real moisture content of various soils. It can measure the volume percentage of soil moisture, which is a soil moisture measurement method in line with current international standards. It can be buried in the soil for a long time, resistant to long-term electrolysis, corrosion resistance, vacuum potting, and completely waterproof.The transmitter is suitable for soil moisture monitoring, scientific experiments, water-saving irrigation, greenhouses, flowers and vegetables, grassland pastures, soil rapid testing, plant cultivation, sewage treatment, precision agriculture and other occasions temperature and humidity, conductivity, PH value testing.
